Theming ProtVista

The same viewer before and after a theme: block: default on the left, themed on the right.

<protvista-uniprot> exposes a documented styling API built on two native web standards, so you can match the viewer to your application with plain CSS and no JavaScript:

• CSS custom properties (--protvista-* design tokens) for colours, sizes and other themable values. This is the primary surface.
• ::part for targeting structural elements of the shadow-DOM datatable (rows, cells, header, filter controls).

Overriding these is the supported way to customise the interface. Internal class names (the hash-prefixed .pv-* classes) are not a public API and may change between releases — theme through the tokens and parts below instead.

Why two mechanisms?

The main viewer and the structure panel render in the light DOM (required by the embedded Mol* structure viewer), so their themable values are exposed as custom properties, which you set on the element or any ancestor. The datatable renders in a shadow root, so in addition to custom properties (which pierce the boundary through inheritance) it also exposes ::part hooks for structural styling that a custom property alone can’t express.

Quick start

/* Theme every ProtVista instance on the page. */
:root {
  --protvista-color-accent: #7b2d8e;
  --protvista-group-label-bg: #efe6f5;
  --protvista-radius: 8px;
}

/* Theme one instance. */
protvista-uniprot#my-viewer {
  --protvista-track-label-bg: #f2f2f2;
}

/* Reach into the datatable's shadow DOM with ::part. */
protvista-uniprot-datatable::part(row-active) {
  outline: 2px solid #7b2d8e;
}

Because tokens are ordinary custom properties, they are also settable at runtime — element.style.setProperty('--protvista-color-accent', …) — which is how an interactive controls panel can drive live theming. A runtime override survives a later setConfig(): a config theme: clears only the tokens its own previous apply wrote, never one you set yourself. The one exception is a token the previous theme: did write — if you overwrite one of those by hand, the next apply clears it along with the rest of that theme’s output. Set such a value through the config theme:, or re-apply it after setConfig().

No-code theming from the config

For authors who don’t write CSS, a subset of the chrome colours can be set directly in the viewer config via the optional top-level theme: block:

theme:
  labelColor: '#e8f5e9' # tints the row-label panel: groups get the colour, tracks a lighter tint
  accentColor: '#0053d6' # focus rings + datatable active-row marker

The component applies each as the matching --protvista-* custom property inline on the host element at mount. Because an inline declaration beats both the :where(:root) default and ordinary page CSS (an inherited :root value or an element-selector rule), a config theme takes precedence over page CSS: a host that needs to override a config-supplied theme must use !important (e.g. protvista-uniprot { --protvista-color-accent: #7b2d8e !important }) or set the token inline on the element itself.

theme.labelColor is a one-colour tint that keeps the shipped hierarchy: it becomes --protvista-group-label-bg, and --protvista-track-label-bg is derived as a light tint of it (25% of your colour over white) — the default grey/white group-vs-track pair, in your hue. To pin either surface exactly, set the explicit fields, which override the derived pair and map one-to-one onto the same tokens:

theme:
  groupLabelColor: '#c8e6c9' # exact group-label background
  trackLabelColor: '#ffffff' # exact track-label background

theme.accentColor maps to --protvista-color-accent, as written. For anything beyond these — or when the page should win over the config — use the CSS tokens directly and don’t set theme in the config.

A themed label brings its own text colour

A background is only half a surface, so the theme: block does not stop at one. For each label surface it paints, the component measures the colour and derives the rest to match:

Derived	Token
Text, whichever of the default body colour and white contrasts better	--protvista-group-label-color, --protvista-track-label-color
Muted text for hidden/dataless rows in customize mode	--protvista-group-label-color-muted, --protvista-track-label-color-muted
The group’s collapse caret	--protvista-caret-color
The group’s hover background	--protvista-group-label-hover-bg

This is why a dark labelColor stays readable: the label text flips to white rather than staying near-black on a near-black fill, and the caret and hover state follow it instead of dropping out. The component always picks the better of the two candidates, but it cannot manufacture contrast a colour doesn’t have: a mid-tone grey near #808080 sits too close to both black and white for any text to clear the AA threshold, so prefer colours that are decisively light or dark. Set any of these tokens in your own CSS with !important if you want a different answer — the config theme writes them inline (see the precedence note above).

Label colours (labelColor, groupLabelColor, trackLabelColor) are resolved to rgb() before they reach the stylesheet, because the text colour is calculated from them. Hex, keywords, rgb() and hsl() are resolved by the browser, as is hwb() on browsers that support it (Chrome/Edge 101+, Firefox 96+, Safari 15+). oklch(), oklab(), lab(), lch() and color() in the srgb, srgb-linear and display-p3 spaces are converted by the viewer itself, so they work even on browsers in the support matrix that cannot parse them. A colour outside the sRGB gamut is clamped per channel rather than gamut-mapped. Values that only mean something where they are used, such as var(), currentcolor and light-dark(), cannot be turned into a fixed colour and are not accepted for labels.

A label colour that doesn’t resolve (a typo, or a syntax not in the list above) is ignored with a console.warn, leaving the token at its default; an explicit groupLabelColor / trackLabelColor that doesn’t resolve falls back to what labelColor would have given. A translucent label colour is composited over the surface first, since its text colour is chosen against the result. The derivation always composites over the shipped white surface, so if your page repaints --protvista-color-surface to something dark, set the label tokens directly rather than theming through the config.

accentColor is not resolved, because nothing is derived from it. It is handed to CSS exactly as you wrote it, so var(--your-brand), light-dark(), alpha and any colour space your browser supports all work. A value the browser does not accept as a colour is ignored with a console.warn.

Design tokens

Every token has a sensible default (shown below), so a viewer with no custom CSS renders exactly as it always has. Component tokens whose default is written as var(--protvista-…) inherit from the global tier, so overriding one global token (e.g. --protvista-color-text) cascades everywhere it is used — wherever you declare it, including on the host element or an ancestor rather than on :root. Setting the component token itself always wins over the global it defaults from. A default of inherit means the token is unset: the property it drives takes the page’s value, as it would on an unstyled element.

Only tokens with a literal default are declared on :root. The ones that default from another token are left undeclared so that an override of the global can reach them from anywhere, and the viewer’s own rules carry the fallback. If your own CSS or script reads one of them, give it a fallback of its own, for example var(--protvista-tooltip-bg, #ffffff).

Global

Token	Type	Default	Purpose
--protvista-font-family	font	inherit	Base font family for viewer chrome.
--protvista-font-size	length	0.8rem	Base font size for viewer chrome.
--protvista-color-accent	color	#0053d6	Accent — focus rings, active-row marker, primary UI.
--protvista-color-text	color	#222222	Default body text colour.
--protvista-color-text-muted	color	#4a5056	Muted/secondary text (tooltip labels, captions).
--protvista-color-surface	color	#ffffff	Surface/background for popovers, panels, and (by default) the neutral viewer chrome cells.
--protvista-color-border	color	#c5c8cc	Default border for popovers and panels.
--protvista-color-disabled	color	#808080	Disabled controls.
--protvista-color-bg-hover	color	#f1f7ff	Background of hovered interactive chrome (buttons, list rows).
--protvista-color-bg-active	color	#e6f3ff	Background of an active/pressed control (toggle buttons).
--protvista-radius	length	4px	Corner radius for popovers and controls.
--protvista-shadow-popover	shadow	0 4px 12px rgb(0 0 0 / 0.15)	Drop shadow for floating popovers.

Viewer (labels, navigation, empty states)

Setting a label background in your own CSS? Set its text colour too. The contrast derivation described above runs only for the config theme: path — CSS cannot choose the readable one of two candidates, and color-mix() is outside this package’s browser support matrix. So if you set --protvista-group-label-bg or --protvista-track-label-bg to something dark, also set the matching --protvista-*-label-color and --protvista-*-label-color-muted, plus --protvista-caret-color and --protvista-group-label-hover-bg for a group label. Otherwise the text keeps the page’s own colour, which may not read on your fill.

The label tokens cover the data rows only. The two cells that bracket them — the navigation label cell above and the credits cell below — are neutral chrome rather than rows, so they stay put when you retint the label column; tinting them made a label colour bleed above and below the rows it describes. They have their own pair, --protvista-chrome-cell-bg / --protvista-chrome-cell-color. If you want the whole column in one colour, set that pair; retinting --protvista-color-surface instead would repaint every popover, tooltip and panel on the page too.

Text works the same way in all four cells. Each has its own token, and none of them is set by default, so an unthemed viewer takes the page’s text colour all the way down the column. A config theme: sets the row labels’ text to whatever reads on the colour it painted, and leaves the two chrome cells alone.

Token	Type	Default	Purpose
--protvista-track-content-width	length	80vw	Width of the track-content (visualisation) column.
--protvista-label-width	length	20vw	Width of the label column (group/track/nav labels, credits).
--protvista-group-label-bg	color	#f1f3f5	Background of collapsible group labels.
--protvista-group-label-hover-bg	color	var(--protvista-color-bg-hover)	Background of a hovered collapsible group label.
--protvista-track-label-bg	color	#ffffff	Background of individual track labels.
--protvista-group-label-color	color	inherit	Text colour of collapsible group labels. Unset by default, so the label takes the page’s text colour.
--protvista-track-label-color	color	inherit	Text colour of individual track labels. Unset by default, so the label takes the page’s text colour.
--protvista-group-label-color-muted	color	var(--protvista-color-text-muted)	Recessive text on a group label — a hidden/dataless group in customize mode.
--protvista-track-label-color-muted	color	var(--protvista-color-text-muted)	Recessive text on a track label — a hidden/dataless track in customize mode.
--protvista-chrome-cell-bg	color	var(--protvista-color-surface)	Background of the neutral chrome cells in the label column (navigation label, credits) — the cells that bracket the data rows without being one.
--protvista-chrome-cell-color	color	inherit	Text colour of the neutral chrome cells in the label column. Unset by default, so the cells take the page’s text colour.
--protvista-track-border-color	color	#e3e6ea	Hairline ruling the viewer grid: between rows, and between the label column and the track area.
--protvista-caret-color	color	#5b6169	Group-label expand/collapse caret.
--protvista-nav-handle-fill	color	darkgrey	Fill of the navigation zoom handles.
--protvista-nav-handle-stroke	color	black	Stroke of the navigation zoom handles.
--protvista-no-results-bg	color	#e4e8eb	Background of the “no results” empty state.

Tooltip

Token	Type	Default	Purpose
--protvista-tooltip-bg	color	var(--protvista-color-surface)	Tooltip background.
--protvista-tooltip-color	color	var(--protvista-color-text)	Tooltip text colour.
--protvista-tooltip-border	color	var(--protvista-color-border)	Tooltip border and arrow colour.
--protvista-tooltip-max-width	length	320px	Maximum tooltip width before text wraps.

Datatable

Token	Type	Default	Purpose
--protvista-datatable-accent	color	var(--protvista-color-accent)	Accent — focus outline, active-row marker.
--protvista-datatable-text-head	color	#1a1a1a	Header-cell text colour.
--protvista-datatable-text-body	color	#2c2c2c	Body-cell text colour.
--protvista-datatable-text-muted	color	#444444	Muted text (e.g. the no-results message).
--protvista-datatable-text-input	color	#333333	Filter <select> text colour.
--protvista-datatable-bg-base	color	var(--protvista-color-surface)	Datatable base background.
--protvista-datatable-bg-header	color	#f8f8f8	Sticky header-row background.
--protvista-datatable-bg-hover	color	#f1f7ff	Row hover/focus background.
--protvista-datatable-bg-active	color	#e6f3ff	Selected/active-row background.
--protvista-datatable-border	color	#e0e0e0	Cell and container borders.
--protvista-datatable-border-input	color	#767676	Filter <select> border.
--protvista-datatable-shadow-header	color	#cccccc	Under-shadow of the sticky header row.
--protvista-datatable-max-height	length	400px	Max height of the scroll container before it scrolls.

Migrating from --protvista-dt-*: the datatable tokens were previously named --protvista-dt-*. Those names still work as aliases for one major cycle — an existing --protvista-dt-primary override, for example, is honoured by --protvista-datatable-accent — but new code should use the --protvista-datatable-* names. If both are set, the --protvista-datatable-* one wins.

The datatable renders in a shadow root, but its tokens are set the same way as every other token on this page: on :root, on an ancestor, on the <protvista-uniprot-datatable> element, or inline. Custom properties inherit through the shadow boundary, so no ::part or !important is needed to retheme it.

Datatable ::part

The datatable (<protvista-uniprot-datatable>, used inside the structure panel) exposes these parts:

Part	Element
scroll-container	The scrolling wrapper around the table.
table	The <table> element.
header	The <thead> header section.
header-cell	Each header <th>.
filter-select	Each column filter <select>.
row	Every body row.
row-active	The selected row (in addition to row).
cell	Every body <td>.
no-results	The empty-state cell shown when a filter matches nothing.

protvista-uniprot-datatable::part(header) {
  background: #1a1a2e;
  color: #fff;
}
protvista-uniprot-datatable::part(row):hover {
  background: #fff7e6;
}

What is not themable here

Data-domain colours — the AlphaFold pLDDT and AlphaMissense pathogenicity ramps, and variant/PTM colours — are semantic data encodings, not interface chrome, so they’re themed through the viewer configuration (registerTheme() / rendering presets) instead of these tokens. Nightingale track internals are also out of scope: the track canvases are rendered by the upstream @nightingale-elements/* components, so only the properties those components choose to expose can be set from here.

On the roadmap

Dark mode is planned as a prefers-color-scheme default token set — the token layer above is the substrate, and the palette itself is the follow-on work. Colour-blind-friendly palettes are part of the viewer’s WCAG accessibility work; the default data palettes have been checked, and the results are on Accessibility and known limitations. Further out, the interactive playground should grow a no-code styling panel that lets non-developers adjust these tokens with live preview.
